1.1 General description
This is a new generation of trail camera.
The camera features the all-new innovative and ultra-clear imaging technology,encompasses smart night vision, blur reduction，and noise reduction technology todeliver high resolution image quality.

Key Features
A. Programmable 2M/4MP /8MP / 16MP / 20MP24MP/30MP/32MP high resolution;
B. Support Full HD ( 4K/2.7K/108OP/720P) video recording;
C. Take color pictures daylight and black white pictures at night;
D. Invisible IR LEDs for flash range as 90ft;
E. Available operation temperature: -30℃to 70℃;
F. Build-In 2.31”TFT Screen to review photo and video in camera;
G. Support standard 5V-12V adapter(Max 12V) and 4AA/8AA/12AA batteries（not include
);8AA/12AA recommend;
H. Extra-long range PIR(More than 85ft);
I. Adjustable PIR sensitivity;

1.2 Application
This camera can be used as an automatic surveillance device for guarding andrecording unexpected intrusion to homes, shops, schools,depots,offices，taxis，worksites,etc. It can also be used as a trail camera for hunting or monitoring animals byrecording the traces of wild animals. It can be left alone for weeks and months, and it willsave event records automatically in digital format.

Description

This camera is a digital Hunting Trail camera. It is an infrared surveillance camera, triggered by any movement of human or animal
monitored by a high sensitive Passive Infrared (PIR) motion sensor, and then automatically captures high quality pictures (up to
24MP) or records video clips (4K or 1080 Full HD). It is resistant against water and snow.level reach IP67. The camera can also be used as a portable digital camera.

Image Sensor	8MP Color CMOS
MIC	Support
LCD	2.31’’ TFT
Keypad	Up/Down/Left/Right/OK/Del/Menu/Shot/Playback
LED	32 pcs 940nm No glow IR LED
PIR	One Long Range PIR(>25m)
Memory Card	Up to 512GB
USB	Mini USB Port
Power Supply	5-12V
Day/Night Mode	Auto
Voltage Detect	Support
Temperature Detect	Support
Switch Mode	Three Mode（ON SENTUP OFF）
Image Size	5MP/8MP/16MP/20MP/32MP
Shooting Numbers	1~5
Video Length	5 ~ 180 sec Programmable
Time Setting	Year/Month/Day Hour:minute:Second
Time lapse	Default Off，5-55Min&1H-8H Programmable
PIR Sensitivity	Adjustable (High / Normal / Low/Off)
PIR Interval	Default 5S，0-55Sec&1-60M Programmable
PIR Angel	120°（>20m）
Language	English(Default), suomi, Deutsch, Svenskt, Dansk, Norsk, Czech, Russian, Italiano, French..17 languages for option
Format SD Card	Support
Default Set	Support
Trigger Time	<0.2s
PIR Detection Range	20m/65ft
IR range	20m/65ft
Video Resolution	4K/2.7K/1080P/720P/480P
Low Power Consumption	<100uA（Battery Mode）
Operation/Storage Temperature	-20 ~ +60°C / -30 ~ +70°C
Operation Humidity	5 % - 90 %
Waterproof	IP67

High Quality  Image Resolution with Panasonic sensorCapture more clear picture both in day and night

>0.3s fast trigger time with 1 PIR,uses imported PIR sensor ,don't need more PIRs to reach the fast trigger speed.Never miss any amazing scences.



32pcs 940nm IR LEDs plus true 8MP CMOS Sensor,make the camera capture more bright and clear image at night.
High level waterproof IP67Our camera can reach IP67 waterproof level coupled with long standby time,so even you leave it outside for long time,don't worry about the power and raining issue. It will be your eyes in any rugged environment.

Product Usage
 High resolution CMOS sensor ,0.2s fast trigger time,32pcs 940nm IR LEDs ,can capture what you want to with high quality image and video no matter in daylight or in total dark environment .
It can be used for animal monitoring or trap,wildlife hunting and observation,plant observation ,home or garden surveillance,farm security burglar
